Mechanical Sauna Timer for 110-240 VAC Sauna Controller Infrared Heaters

Mechanical Sauna Timer for 110-240 VAC Sauna Controller Infrared Heaters

US $82.00

Ideal sauna timer for all sauna heaters. Works with 110 VAC as well as 220 VAC sauna heaters. Great for Infrared sauna heater controller.

Mechanical Sauna Timer for 110-240 VAC Sauna Controller Infrared Heaters

Ideal sauna timer for all sauna heaters. Works with 110 VAC as well as 220 VAC sauna heaters. Great for Infrared sauna heater controller.

This NSi Industries C460M spring-wound timed switch accepts 120/277 VAC input and its DPST output contacts can activate a 20 amp load or 2 hp motor. The timer's twist knob sets time from one minute to 12 hours with an automatic Off. The double-pole single-throw (DPST) contacts are housed within a single-gang in-wall switch with metal cover plate that is suitable for indoor use and is Underwriter Laboratories (UL) Listed and Canadian Standards Association (CSA) certified for quality assurance. This switch is suitable for controlling lighting and fans and Infrared sauna heaters under 20 Amps.

Specification:

Switch TypeSpring Wound Timer with Twist Knob
Input power supply 120/277 VAC, 50/60 Hz
Output contacts DPST contacts, 20 amps load rating, 2 hp motor load rating
On/off control One minute to 12 hours with auto Off
Enclosure Single-gang in-wall, indoor use, metal cover plate
Terminal wire size range #12 AWG (American wire gauge)
Operating temperature range 32 to +122 degrees F (0 to +50 degrees C)
Standards met UL Listed, CSA certified



Dimension (L x W x H) 0 x 0 x 0 Inch
Weight 1 Pound
